Wear-resistance 95% Alumina Ceramic Tube High Hardness And Wear Resistance Ceramic Bush

Name: Wear-resistance 95% Alumina Ceramic Tube High Hardness And Wear Resistance Ceramic Bush
Brand: HaoRui
Rating: 5.0 (13 reviews)

Very good electrical insulation.
Moderate to extremely high mechanical strength.
Very high compressive strength.
High hardness.
Moderate thermal conductivity.
High corrosion and wear resistance.
Good gliding properties.
Low density.
Operating temperature without mechanical load 1,000 to 1,700°C.
Bioinert and food compatible.

Availability:

Quantity:



Inquire Add to Basket

Model:
01024
Brand:
HaoRui
Code:
custom01024

Product Description

Overview

Alumina or aluminum oxide (Al2O3) is a major engineering material. It offers a combination of good mechanical properties and electrical properties. It is used more often than any other advanced ceramic material.

Alumina ceramics are commonly subdivided according to their alumina content ranging from 80% to more than 99%. Alumina can be produced in a range of purities with additives designed to enhance properties. Higher purity alumina demonstrates enhanced wear and corrosion resistance.

A wide variety of ceramic processing methods can be applied including machining or net shape forming to produce a wide variety of sizes and shapes of component. In addition, it can be readily joined to metals or other ceramics using metallising and brazing techniques.

Alumina based ceramics are by far the largest range of advanced ceramics made by HaoRui. Due to the important combination of properties, we have thoroughly researched the behaviour and characteristics of our alumina products to give you the best possible component.

Product Description

Alumina was quickly adopted by the electronics industry due to its high electrical insulation properties. In addition, because it has excellent corrosion resistance, wear resistance, and mechanical strength, it is used in many industrial machinery parts, and is the most widely used Fine ceramic material.

900X900-F2 900X900-F5 900X900-F4

Our Services

SHENZHEN HAORUI can offer not only qualified products, we can also supplying quality service including design, development, export and after sales. Our team is happy to provide guidance, answer any questions you may have, provide technical support or respond to your feedback about our service.

Shenzhen Haorui Industrial Technology Co., Ltd. was established in June 2006. It is an enterprise specializing in R&D, manufacturing, and sales of engineering ceramics. After Twenty years of development, we have accumulated rich industry experience and trained a group of professional technicians. We have a complete production process and quality management system, as well as a complete set of precision processing equipment and testing equipment. Our dedication to innovation and excellence drives us to continuously improve our products and services to meet the evolving needs of our customers.

Properties of Alumina

The Most Well-known Oxide Ceramic Material

Properties of Alumina/Aluminum Oxide (Al2O3)

Very good electrical insulation.
Moderate to extremely high mechanical strength.
Very high compressive strength.
High hardness.
Moderate thermal conductivity.
High corrosion and wear resistance.
Good gliding properties.
Low density.
Operating temperature without mechanical load 1,000 to 1,700°C.
Bioinert and food compatible.

Property	Item	95% Al2O3	99% Al2O3	99.8%Al2O3	Unit
Mechanical Characteristics	Color	White	light yellow	Ivory
	Bulk Density	3.7	3.85	3.93	g/cm³
	Water Absorption	0	0	0	%
	Bending Strength	300	310	370	MPa
	Compressive Trength	2,300	2,400	2500	MPa
	Elastic Modulus	320	340	390	GPa
	Fracture Toughness	3~4	3~4	4	MPa m^1/2
	Weber Coefficient	12	12	12	m
	Vickers Hardness	1,400	1,600	1850	HV 0.5
Thermal Characterics	Coefficient of Line Thermal Expansion	7~8	7~8	7~8	10^-6 K^-1
	Thermal Conductivity	20	29	32	W/mK
	Thermal Shock Resistance (Put in Water)	250	200	280	ΔT °C
	Max Working Temperature	1,500	1,600	1700	°C
Electrical Characteristics	Volume Resistance At 20°C	>10¹⁴	>10¹⁴	>10¹⁴	Ωcm
	Dielectric Strength	15×10⁶	15×10⁶	15×10⁶	V/m
	Dielectric Constant	9	10	10	εr
	One MHZ Dielectric Loss Angle at 20°C	0.0004	0.0002	0.0001	tanδ
Chemical Characteristics	Nitric Acid (60%) 90°C	0.1	0.1	0.05	24H WT Loss mg/cm²
	Sulphuric Acid (95%) 95°C	0.3	0.34	0.22
	Caustic Soda (30%) 80°C	0.9	0.95	0.04

Wear-Resistance 95% Alumina Ceramic Tube: High Hardness and Wear Resistance Ceramic Bush

Our Wear-Resistance 95% Alumina Ceramic Tube is designed to offer exceptional performance in challenging industrial applications. Made from high-quality 95% alumina ceramic, this product delivers outstanding wear resistance, high hardness, and superior mechanical strength, ensuring long-lasting durability even in the most demanding conditions.

Key Features:

High Hardness: The 95% alumina ceramic bush offers impressive hardness, making it highly resistant to abrasion and mechanical wear. It is the ideal solution for industries where components are subject to friction and heavy usage.
Superior Wear Resistance: The alumina ceramic tube provides excellent wear resistance, making it suitable for environments where components are exposed to high levels of mechanical stress and material flow.
High-Temperature Stability: With the ability to withstand temperatures of up to 1600°C, this ceramic bush performs exceptionally well in high-temperature applications without losing structural integrity.
Corrosion Resistance: The alumina ceramic tube is resistant to a wide range of chemicals, acids, and alkalis, making it perfect for use in harsh chemical environments, preventing corrosion and degradation over time.
Customizable Sizes and Shapes: Our alumina ceramic bush can be customized according to your specific requirements, allowing for a wide range of applications in various industries, including machinery, electrical components, and chemical processing.

Applications:

Wear Protection: Ideal for use in machinery components, this ceramic bush provides excellent wear protection in high-stress environments, such as mining, chemical processing, and material handling.
High-Temperature Environments: The alumina ceramic tube is highly effective in furnaces, kilns, and other high-temperature industrial processes, offering reliable performance and durability.
Corrosion-Resistant Applications: Suitable for chemical processing plants and industries where exposure to harsh chemicals is common.

Our wear-resistance alumina ceramic tubes and ceramic bushings are engineered for long-lasting performance, making them the best choice for industries that require high wear resistance, hardness, and durability. Choose our 95% alumina ceramic solutions for reliable protection and enhanced efficiency in your industrial processes.
