Isostatic Pressed ZrO2 Zirconia Ceramic Tube pipe Custom Industrial Ceramic Parts

Share to:

Custom ZrO2 Zirconia Ceramic Tubes and Parts

Name: Custom ZrO2 Zirconia Ceramic Tubes and Parts
Brand: HaoRui
Rating: 5.0 (80 reviews)

★Edge opening, very sharp
★Extremely high bending strength and hardness
★High density - up to 6.0 g/cm^3
★Low thermal conductivity
★Other features: high electrical insulation, high corrosion resistance, high biocompatibility

Category: Zirconia Ceramic Parts
Tags: Industrial Applications

Availability:

Quantity:



Inquire Add to Basket

Model:
02A36
Brand:
HaoRui
Code:
custom01A35

Product Description

Place of Origin

Guangdong, China

Type

Ceramic Tubes

Application

Industrial Ceramic

Model Number

ZrO2-036

Brand Name

HaoRui

Processing Service

Cutting, Moulding, Grinding, Milling, Drilling, Lapping, Polishing, CNC, Laser

Product name

Precision ceramic parts

Color

White/Ivory

Shape

Customized

Dimension

Customized

Quality control

100% Inspection

Feature

High hardness, High strength, High temperacture

Max Working Temperature

1000℃

Gas permeability

0

Water Absorption

0

MOQ

1 Pcs

Properties Of Different Zirconia Material

Property	Item	3Y-TZP White /Black		Mg-PSZ		Nano 3Y-TZP
Mechanical Characteristics	Color	Ivory/Black	-	Gold Yellow	-	BLUE	-
	Density	6.02	g/cm3	5.7	g/cm3	6.01	g/cm3
	Bending Strength	800	MPa	450	MPa	1200	MPa
	Compressive trength	3000	MPa	2500	MPa	3000	MPa
	Elastic Modulus	200	GPa	250	GPa	220	GPa
	Fracture Toughness	8	MPa m1/2	6~7	MPa m1/2	14	MPa m1/2
	Weber Coefficient	15	m	12	m	25	m
	Vickers Hardness	1200	HV 0.5	1100	HV 0.5	1200	HV 0.5
Thermal Characterics	Coefficient of Line Thermal Expansion	10	10^-6K^-1	10	10^-6K^-1	10	10^-6K^-1
	Thermal Conductivity	3	W/mK	3	W/mK	2	W/mK
	Thermal Shock Resistance(Put in Water)	300	ΔT °C	450	ΔT °C	300	ΔT °C
	Max Working Temperature	1000	°C	2100	°C	1000	°C
Electrical Characteristics	Volume Resistance at 20°C	>10¹³	Ωcm	>10¹⁴	Ωcm	>10¹³	Ωcm
	Dielectric Strength	11×10⁶	V/m	13 × 10⁵	V/m	11×10⁶	V/m
	Dielectric Constant	33	εr	28	εr	33	εr
	One MHZ Dielectric Loss Angle at 20°C	0.0016	tanδ	0.0017	tanδ	0.0016	tanδ
Chemical Characteristics	Nitric Acid (60%) 90°C	≒0.00	WT Loss mg/cm²/day	0.1	WT Loss mg/cm²/day	≒0.00	WT Loss mg/cm²/day
	Sulphuric Acid (95%) 95°C	0.04		0.34		0.03
	Caustic Soda (30%) 80°C	0.08		0.95		0.06
This data is the result of laboratory testing. Customers need to judge whether it can be used according to the specific environment.

Isostatic Pressed ZrO2 Zirconia Ceramic Tube Pipe: Custom Industrial Ceramic Parts

Our Isostatic Pressed ZrO2 Zirconia Ceramic Tube Pipe offers superior performance in demanding industrial environments. Made from Zirconium Oxide Ceramic (ZrO2), these ceramic parts are renowned for their exceptional strength, fracture toughness, and thermal stability, making them the perfect solution for various applications.

Key Features:

High Strength and Toughness: Yttria Stabilized Zirconia (YSZ) provides remarkable mechanical strength and fracture resistance, ensuring long-lasting durability even in extreme conditions.
Thermal Stability: The Zirconia Ceramic has excellent thermal stability, making it suitable for high-temperature applications, withstanding temperatures up to 2400°C.
Wear Resistance: These ZrO2 ceramic parts exhibit outstanding wear resistance, ensuring minimal degradation in high-friction environments and extending the lifespan of components.
Corrosion Resistance: Zirconia ceramics offer excellent resistance to corrosion from harsh chemicals, acids, and alkalis, ensuring their reliability in aggressive environments.
Customizable Design: Our isostatic pressed zirconia ceramic tubes and pipes can be customized to meet specific industrial needs, including different dimensions and tolerances.

Applications:

Mechanical and Structural Components: Ideal for applications requiring high mechanical strength and resistance to wear and corrosion.
High-Temperature Environments: Suitable for use in furnaces, thermal barriers, and kilns, due to its exceptional thermal stability.
Chemical Processing: Perfect for industries where chemical resistance is crucial, such as in chemical reactors and piping systems.

Choose our custom industrial zirconia ceramic parts for reliable, high-performance solutions in industries requiring yttria-stabilized zirconia and high-purity ZrO2 ceramics. These components offer superior toughness, durability, and versatility for a wide range of industrial applications.
